Description
Highlights:
1.Sturdy Aluminum Profiles: The frame is mainly made of aluminum alloy and bake lite materials, with high strength and high precision. It also has two pieces of acrylic bezels on both sides, so you can securely monitor the engraving process.
2.Three Axes: Three refined axes are designed to achieve plane engraving. With the knob, the axes can be moved manually, which facilitates the carving tool settings. The driving units consist of T8 stainless steel screw rods whose lead distance is 4 mm.
3.Grbl & Offline Control: The GRBL control features an XYZ axis drive and full functionality. And the advantages of the offline controller lies in the following ones: 1. No need to connect to the computer. 2. Arbitrary selection of offline files for engraving. 3. Manually adjust the X, Y, and Z axes position as the engraving starting point.
4.High-Speed Motors: This CNC engraving machine is equipped with three 42 stepper motors and a 775 (12-36V) spindle motor with a rotational speed of 10000r/min. An extra 15000mw laser whose wavelength is 450 nm is available for you. And the engraver supports Windows XP SP3, win7, win8, win10 (32/64), macOS system, and other software to directly import JPG, BMP, PNG, DXF format files for engraving.
5.Easy Operation: We provide a detailed user manual, assembly instructions, and installation video. Assemble according to the installation instructions; then, you can enjoy the delight of engraving plastics, soft aluminum, and many more.
Details:
![]()
![]()
CNC 3018 Pro MAX Engraving Machine
This CNC engraving machine is made of aluminum and bake lite. It features a USB port, GRBL control board, and an offline controller, convenient for you to operate efficiently with/without computers. It is an ideal tool to engrave all types of plastics, soft aluminum, wood, PVC, etc.
-
Superior Aluminum Profiles
-
-
-
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
Aluminum Material
Constructed with aluminum alloy and bakelite materials, the CNC 3018 Pro is rustproof, hard-wearing and durable. Two pieces of acrylic baffles on both sides help you monitor the engraving process conveniently.
Three Refined Axes
The axes are equipped with knobs to help you move the carving machine manually, significantly improving working efficiency for a precise carving setting.
GRBL Control Board
The GRBL control board could be connected to a computer via a USB interface. And the 3Pin laser driver interfaces support PWM, TTL functions for full function laser engraving.
Offline Controller
An offline controller of the CNC router is also included for easy remote control without a computer to improve your working efficiency.
High-efficiency Motors
There are three 42 stepper motors on three axes for smooth movement. The 775 (12-36V)24V spindle motor on the Z-axis can reach the speed of 10000r/min.
Extensive Application
This CNC engraving machine can engrave all types of plastics, soft aluminum, woods, acrylics, PVCs, PCBs, and a wide range of other soft materials.
-
-
Effective Working Area(X x Y x Z): 11.8" x 7.1" x 1.8" / 300 x 180 x 45 mm
-
Materials: Aluminum Profile & Bakelite
-
Control Software: GRBL Control
-
-
-
Stepping Motor: Size 42, 12V; Torque: 0.25 N/m
-
Driving Units: T8 Stainless Steel Screws
-
Cutter Diameter: 0.125" / 3.175 mm
-
Positioning Accuracy: 0.003"-0.004" / 0.08-0.1 mm
-
Item Dimension: 15.7" x 11.8" x 9.4" / 400 x 300 x 240 mm
-
-
-
-
1 x U-Disk (Software & Instruction)
-
1 x Set of Milling Cutter
-
1 x Pair of Protective Glasses
-
-
-
-
-
-
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
CNC 3018 Pro MAX Engraving Machine
This CNC engraving machine is made of aluminum and bake lite. It features a USB port, GRBL control board, and an offline controller, convenient for you to operate efficiently with/without computers. It is an ideal tool to engrave all types of plastics, soft aluminum, wood, PVC, etc.
- Superior Aluminum Profiles
- Three Axes
- GRBL & Offline Control
- High-Speed Motors
Aluminum Material
Constructed with aluminum alloy and bakelite materials, the CNC 3018 Pro is rustproof, hard-wearing and durable. Two pieces of acrylic baffles on both sides help you monitor the engraving process conveniently.
Three Refined Axes
The axes are equipped with knobs to help you move the carving machine manually, significantly improving working efficiency for a precise carving setting.
GRBL Control Board
The GRBL control board could be connected to a computer via a USB interface. And the 3Pin laser driver interfaces support PWM, TTL functions for full function laser engraving.
Offline Controller
An offline controller of the CNC router is also included for easy remote control without a computer to improve your working efficiency.
High-efficiency Motors
There are three 42 stepper motors on three axes for smooth movement. The 775 (12-36V)24V spindle motor on the Z-axis can reach the speed of 10000r/min.
